Lean-To Storage Shed

See All Shed Styles

Lean-To Style Shed

7' Tall Short Side Wall
Base Price Includes:
  • 4' Wide Single Door
  • Comes primed & ready to paint (paint option is 12% of base price)
  • 30 yr. Architectural Shingles
  • All standard features listed under specifications tab
  • Installation & Delivery (within our standard delivery radius)
See Photo Gallery
Shed Size Classic Series Pricing Premium Series Pricing
4' X 6' $1,786 $1,954
4' X 8' $2,078 $2,251
4' X 10' $2,330 $2,542
4' X 12' $2,542 $2,761
4' X 16' $3,041 $3,310
6' X 6' $2,178 $2,397
6' X 8' $2,419 $2,666
6' X 10' $2,806 $3,086
6' X 12' $3,030 $3,321
6' X 14' $3,287 $3,618
6' X 16' $3,657 $4,004
6' X 20' $4,570 $4,995
8' X 8' $2,811 $3,114
8' X 10' $3,147 $3,444
8' X 12' $3,545 $3,914
8' X 14' $3,909 $4,323
8' X 16' $4,318 $4,698
8' X 20' $5,012 $5,460
10' X 10' $3,707 $4,127
10' X 12' $4,105 $4,547
10' X 14' $4,581 $5,029
10' X 16' $5,029 $5,482
10' X 20' $5,796 $6,378
12' X 12' $4,754 $5,236
12' X 14' $5,225 $5,757
12' X 16' $5,695 $6,261
Standard Apex
Custom Options Pricing
Door Options
Standard 4' Single Door - 1 included in base price
Prices for all other doors are upgrades
Extra Single Door $165
6' Double Door (upgrade) $195
8' Double Door (upgrade) $235
Transom windows in doors
Transom in Single Door $165
Transoms in 6' Double Door $260
Transoms in 8' Double Door $340
Window Options
Single Hung Window (slides up and down)
12" X 18" SH Window $110
14" x 21" SH Window $125
18" x 24" SH Window $135
24" x 30" SH Window $185
24" X 36" SH WIndow $215
Slider Windows (slides side to side)
24" x 24" Slider Window $170
36" x 24" Slider $215
36" X 36" Slider $245
48" X 36" Slider $315
Transom Windows
29" Transom Window $160
40" Transom Window $165
46" Transom Window $175
72" Transom Window $195
Vents & Skylights
16" x 6" Wall Vent $20
Roof Vent $65
Translucent Roof Vent $85
Shelves
16" Deep Shelving $5.50 / lin. ft.
20" Deep Shelving $6.50 / lin. ft.
24" Deep Shelving $6.50 / lin. ft.
Roof Overhang Options
Standard = 4" on Eaves Only Included
6" Overhang (all 4 sides) $6 / lin. ft.
12" Overhang (all 4 sides) $12.50 / lin. ft.
Custom Roof Pitch Options
4/12 Pitch Standard
6/12 Pitch $2.50 / sq. ft.
8/12 Pitch $6 / sq. ft.
10/12 Pitch $8 / sq. ft.
Other Options
Pegboard $60 per sheet
Set of Ramps $85
Porch Call
Deck Call

Classic Series Specifications

Lean-To Shed rendering with callouts for features
  • Building Heights
    • 1   7' Exterior Short Wall Height
    • 2   Height to Peak from bottom of shed
              • 4' Wide = 8'7"
              • 6' Wide = 9'1"
              • 8' Wide = 9'9"
              • 10' Wide = 10'5"
              • 12' Wide = 10'11"
      May be shorted by changing roof pitch to 2/12
  • Floor Construction
    • 3   2 X 6 "Osmose" Floor Joist System
              • Ground Contact Impregnated Pressure Treated Floor Joists
              • Lifetime Ground Contact Warranty
              • 24" O.C. Joist Spacing
    • 4   3/4" Tongue & Groove OSB Engineered Floor Sheeting
  • Wall Construction
    • 5   Premium 2x4 Studs with 24" O.C. Stud Spacing
    • 6   LP SmartSide Engineered Structural Siding
              • Factory Primed for superior paint adhesion
              • Treated to prevent fungal decay and termites
              • SmartGuard Process - Resists moisture and swelling
              • 50 year Limited Warranty
    • 7   3-1/2" SmartSide Trim
      • Same material as siding
    • 8   2-1/2" Siding Overlap on floor
      • Seals out moisture and prevents floor rot
      • Siding is attached to floor joists for greater wall strength
      • NOBODY ELSE DOES THIS!
  • Roof Construction
    • 9   Premium Rafters
              •  3/12 Roof Pitch (2/12 pitch available)
              •  4" Roof overhang on short wall eave only
  • Roofing Materials
    • 10   Premium synthetic roof underlayment (better than tar or felt paper)
    • 11   Full perimeter metal drip edge
    • 12   Certainteed Brand Landmark Lifetime Warranty Shingles
  • Paint Options
    • Sherwin-Williams premium A-100 Paint
    • No cheap contractor grade paint
    • 15 year Paint Warranty
    • More color options than any of our competitors
  • Door Specifications
    • Standard Door: 4' wide single door
         • 76" tall if on end wall or tall wall
         • 72-1/2" tall if on short side wall
    • Heavy Duty 6" T-Hinges with 2-1/2" Hinge Screws
    • Heavy duty Apex keyed locking L-handle with easy close slam latch
    • Inside door handle
  • Installation
    • On-site construction and installation included
    • FREE DELIVERY within 70 miles of Springville, Utah
    • 5 Year Workmanship Warranty

Premium Series Specifications

Lean-To rendering with callouts for features
  • RED = Premium Series Exclusive Features
  • Building Heights
    • 1   7' Exterior Short Wall Height
    • 2   Height to Peak from bottom of shed
              • 4' Wide = 8'7"
              • 6' Wide = 9'1"
              • 8' Wide = 9'9"
              • 10' Wide = 10'5"
              • 12' Wide = 10'11"
      May be shorted by changing roof pitch to 2/12
  • Floor Construction
    • 3   2 X 6 "Osmose" Floor Joist System
              • Ground Contact Impregnated Pressure Treated Floor Joists
              • Lifetime Ground Contact Warranty
              • 24" O.C. Joist Spacing
    • 4   3/4" Tongue & Groove OSB Engineered Floor Sheeting
  • Wall Construction
    • 5   Premium 2x4 Studs with 16" O.C. Stud Spacing
    • 6   LP SmartSide Engineered Structural Siding
              • Factory Primed for superior paint adhesion
              • Treated to prevent fungal decay and termites
              • SmartGuard Process - Resists moisture and swelling
              • 50 year Limited Warranty
    • 7   3-1/2" SmartSide Trim
      • Same material as siding
    • 8   2-1/2" Siding Overlap on floor
      • Seals out moisture and prevents floor rot
      • Siding is attached to floor joists for greater wall strength
      • NOBODY ELSE DOES THIS!
    • 9   Z-Flashing on all Horizontal siding seams
              • Better seals against moisture and insects
  • Roof Construction
    • 10   Premium Rafters
              •  3/12 Roof Pitch (2/12 pitch available)
              •  4" Roof overhang on short wall eave only
  • Roofing Materials
    • 11   Premium synthetic roof underlayment (better than tar or felt paper)
    • 12   Full perimeter metal drip edge
    • 13   Certainteed Brand Landmark Lifetime Warranty Shingles
  • Door Specifications
  • 14   Aluminum Threshold on Door Entry
    • Standard Door: 4' wide single door
         • 76" tall if on end wall or tall wall
         • 72-1/2" tall if on short side wall
    • Heavy Duty 6" T-Hinges with 2-1/2" Hinge Screws
    • Heavy duty Apex keyed locking L-handle with easy close slam latch
    • Inside door handle
  • Paint Options
    • Sherwin-Williams premium A-100 Paint
    • No cheap contractor grade paint
    • 15 year Paint Warranty
    • More color options than any of our competitors
  • Installation
    • On-site construction and installation included
    • FREE DELIVERY within 70 miles of Springville, Utah
    • 10 Year Workmanship Warranty

Our Lean-to Storage Sheds are perfect for putting up next to an existing building or other structure. It can almost looks like an addition to you home when properly designed. In most cases, the door can go on any side making this a versatile storage addition to anyone's back yard.  These building have a very modern shed look with a single slope roof to allow water to run off of one side of the shed. Call us at Apex Shed Company for a Free On-site Estimate. We can build the Storage Shed, Garage or Playhouse of your dreams.

Lean-To style sheds are great for many reasons.  The standard door height when the door is placed on the end wall or tall wall is 6'-4".  When the door is placed on the short side wall, the height is 72-1/2" due to the header that is needed to support the weight of the trusses.   The 7' height is the exterior siding height on the shortest wall.  Actual interior wall height varies a little depending on the width of the shed due to the larger rafters required for wider sheds

This shed is comparable in size to models of other shed manufacturers.  In order to help you compare apples to apples, we have included a list of comparable models from other companies below.

Classic or Premium Series?  What's right for me?

Compare the differences between our Classic Series and our Premium Series Quality Levels

All of our sheds are built using the same high quality materials. From the exterior you cannot tell the difference between our Premium and Classic Series buildings. There are just a few subtle but important differences between them that make the classic series a little more affordable. Both will provide years of reliable protection of your belongings from the elements.

Classic Series

  • 24" On Center Stud Spacing
  • All other Standard Construction Materials and Features
  • Still meets code and snow load requirements for most areas

Premium Series

  • 16" On Center Stud Spacing
  • Z-Flashing on all Horizontal Seams. (extra protection against the weather)
  • Aluminum Threshold on Door Entry (Protect the edge of the floor from chipping and other damage)

All other features are identical and both will provide years of reliable protection of your belongings from the elements. For more information see the specifications tabs above.
